The Honeywell RM7800 is a microprocessor-based integrated burner control designed for automatically fired gas, oil, or combination fuel single-burner applications. It is part of the 7800 Series, which includes models like RM7800E, G, L, M, and others. This control platform replaces traditional electromechanical systems, offering advanced reliability and programmable features. The RM7800 is SIL 3 capable and supports UL/CSA On/Off, Modulating, and FM/IRI Modulating burner applications. It is a key component for modern combustion systems, ensuring safety and efficiency. The user manual provides detailed installation, operation, and troubleshooting guidelines.

Key Features and Benefits

The Honeywell RM7800 Relay Module is a state-of-the-art, microprocessor-based integrated burner control designed to enhance the safety, efficiency, and reliability of combustion systems. It is specifically engineered for automatically fired gas, oil, or combination fuel single-burner applications. Below are the key features and benefits of the Honeywell RM7800:

• Microprocessor-Based Technology: The RM7800 utilizes advanced microprocessor technology to provide precise control over burner operations, ensuring consistent performance and reliability.
• Multiple Burner Applications: It supports UL/CSA On/Off, Modulating, and FM/IRI Modulating burner applications, making it versatile for various industrial and commercial needs.
• Safety Shutdown (Lockout): The module incorporates a safety shutdown feature that initiates if any malfunction or unsafe condition is detected, ensuring protection against potential hazards.
• Flame Detection and Monitoring: The RM7800 works seamlessly with Honeywell flame rods and photocells to provide accurate flame detection, ensuring reliable burner operation and safety.
• SIL 3 Capability: The RM7800 is SIL 3 capable, meeting stringent safety integrity levels for industrial applications, making it a robust choice for critical systems.
• User-Friendly Interface: The module is designed for easy operation, with clear indicators and controls that simplify setup, troubleshooting, and maintenance.
• Compatibility with Auxiliary Devices: It supports integration with Honeywell’s range of accessories, including pressure switches, flame amplifiers, and purge cards, ensuring a comprehensive control system.
• Valve Proving System: The RM7800 facilitates valve proving, which verifies the proper operation of safety shut-off valves, adding an extra layer of safety to the system.
• Compliance with Standards: The module meets global safety standards, including UL, CSA, and FM, ensuring compliance and reliability in diverse regulatory environments.
• Compact and Durable Design: The RM7800 is built to withstand harsh industrial environments, with a compact design that allows for easy installation and maintenance.

These features and benefits make the Honeywell RM7800 an ideal solution for modern combustion systems, offering enhanced safety, efficiency, and operational flexibility. Its advanced technology and compatibility with a wide range of applications ensure it meets the demands of industrial and commercial burner control systems.

Installation Instructions

Installing the Honeywell RM7800 requires careful preparation and adherence to the manual. Begin by ensuring all pre-installation checks are completed, including verifying compatibility with existing systems. Mount the module securely, following the provided dimensions for proper alignment. Wiring connections should be made according to the diagram, ensuring all terminals are correctly matched. Perform a final wiring check to confirm connections are secure and correct. Refer to the manual for specific instructions on configuring the module and performing initial system tests to ensure proper operation.

3.1 Pre-Installation Checks

Before installing the Honeywell RM7800 Relay Module, several pre-installation checks must be performed to ensure a safe and successful installation. These checks are critical to verify compatibility, safety, and proper system operation.

• Environmental Conditions: Verify that the installation environment meets the specified temperature and humidity requirements. The RM7800 operates effectively in temperatures ranging from -18°C to 60°C (-0°F to 140°F) and a relative humidity of 0 to 95% non-condensing. Ensure the location is free from corrosive substances and excessive vibrations.
• System Compatibility: Confirm that the RM7800 is compatible with the burner system, fuel type, and control requirements. The module supports gas, oil, or combination fuel applications and is designed for UL/CSA On/Off, Modulating, and FM/IRI Modulating burner applications. Ensure the module is suitable for the specific burner configuration.
• Power Supply: Check the power supply requirements. The RM7800 typically operates on 120/230 VAC, 50/60 Hz. Verify that the power source matches the module’s specifications and is properly grounded to prevent electrical hazards.
• Safety Features: Familiarize yourself with the safety shutdown features of the RM7800. The module is designed to shut down the burner in case of faults such as flame failure, pressure switch issues, or other critical errors. Ensure all safety mechanisms are functional and properly connected.
• Manual Review: Thoroughly review the Honeywell RM7800 manual to understand the installation process, wiring diagrams, and safety precautions. Pay attention to specific instructions for your model, as slight variations may exist between RM7800E, G, L, M, and other variants.
• Physical Inspection: Inspect the module for any damage or wear. Ensure all terminals and connectors are clean and free of corrosion. If the module has been stored for an extended period, check for any signs of moisture or tampering.

By completing these pre-installation checks, you can ensure that the Honeywell RM7800 is installed safely and functions optimally. Failure to perform these checks may result in improper operation, safety hazards, or damage to the module and connected equipment. Always consult the official Honeywell resources or contact a certified technician if you encounter any uncertainties during the process.

3.2 Mounting the Module

Mouting the Honeywell RM7800 Relay Module is a critical step in the installation process. Proper mounting ensures the module operates efficiently, maintains reliability, and adheres to safety standards. Follow these guidelines to mount the module correctly.

Key Considerations

• Location Selection: Choose a location that is easily accessible for maintenance and operation. The module should be mounted near the burner control system to minimize wiring complexity.
• Environmental Protection: Ensure the mounting location is protected from exposure to direct sunlight, moisture, and extreme temperatures. The RM7800 is designed for indoor use, but if installed outdoors, it must be housed in a weatherproof enclosure.
• Compatibility: Verify that the mounting surface is compatible with the module’s dimensions and weight. The RM7800 is lightweight and compact, making it suitable for wall or DIN rail mounting.

Mounting Instructions

1. Prepare the Module: Before mounting, ensure the RM7800 is free from packaging materials and any protective covering. Inspect the module for damage or defects.
2. Wall Mounting:
   1. Locate the mounting holes on the back of the module. These holes are designed for screw fixation.
   2. Drill pilot holes in the wall to match the screw positions. Use anchors if necessary, especially for drywall or plaster surfaces.
   3. Secure the module to the wall using the provided screws. Tighten firmly but avoid over-tightening, which could damage the module.
3. DIN Rail Mounting:
   1. Ensure the DIN rail is compatible with the module’s dimensions (35mm standard DIN rail).
   2. Align the module’s DIN rail clips with the rail and slide it into place.



   3. Gently push the module until it clicks securely onto the rail.
4. Leveling and Securing: Once mounted, use a spirit level to ensure the module is properly aligned. Adjust if necessary to prevent uneven installation, which could lead to vibration or operational issues.
5. Final Check: Verify that the module is securely fastened and does not move when touched. Ensure all cables and connectors are safely routed away from the mounting area to prevent damage.

By following these mounting guidelines, you can ensure the Honeywell RM7800 is installed correctly and operates reliably. Always refer to the official manual or consult a certified technician if you encounter any doubts during the process.

3.3 Wiring Connections

Proper wiring of the Honeywell RM7800 Relay Module is essential for safe and reliable operation. Incorrect wiring can lead to malfunctions, safety hazards, or damage to the module. Follow these guidelines carefully to ensure accurate connections.

Key Considerations

• Refer to the Wiring Diagram: Always use the wiring diagram provided in the user manual specific to your RM7800 model. Diagrams may vary depending on the burner application (gas, oil, or combination fuel).
• Terminal Identification: The RM7800 has clearly labeled terminals for power supply, inputs, and outputs. Verify each terminal’s function before making connections.
• Use Correct Wire Sizes: Ensure wires are appropriately sized for the current ratings of the module and connected devices. Consult the technical specifications for detailed current ratings.
• Safety Precautions: Disconnect power to the system before starting wiring. Use insulated tools to prevent shock or short circuits.

Wiring Steps

1. Power Supply Connections:

   Connect the power supply to the designated terminals (typically marked as L1 and N for line and neutral). Ensure the voltage matches the module’s rating (e.g., 120VAC or 230VAC). Secure the wires firmly to prevent loose connections.

2. Input/Output Connections:

   Connect input devices such as sensors, switches, and flame detectors to the appropriate input terminals. Output terminals should be connected to the burner, valves, and other control devices. Refer to the wiring diagram for specific assignments.

3. Grounding:

   Ensure the module is properly grounded to prevent electrical noise and ensure safe operation. Connect the ground wire to the designated ground terminal on the module and to a reliable earth point.

4. Flame Detection and Safety Circuits:

   Connect flame detection devices (e.g., photocells or flame rods) to the module’s flame sensing terminals. These connections are critical for safe burner operation and shutdown in case of flame failure.



5. Valve Proving and Safety Shutdown:

   Connect valve proving systems and safety shutdown circuits according to the wiring diagram. These connections ensure the burner shuts down safely in case of malfunction or hazardous conditions.

Final Checks

After completing all connections, perform a visual inspection to ensure wires are securely fastened and properly routed. Use a multimeter to verify continuity and check for short circuits. Power up the system and test all functions to confirm correct operation.

By following these wiring guidelines, you can ensure the Honeywell RM7800 operates safely and efficiently. Always consult the user manual or contact a certified technician if you encounter any issues during the wiring process.

Operational Features

The Honeywell RM7800 offers advanced operational features, including microprocessor-based control for precise burner management. It supports valve proving systems for gas applications and flame detection for safe operation. The module is designed for On/Off, Modulating, and combination fuel systems, ensuring flexibility. With SIL 3 capability, it meets high safety standards. Enhanced diagnostics and programmable settings allow for tailored control, making it suitable for various industrial applications.

4.1 Modes of Operation

The Honeywell RM7800 Relay Module operates in several distinct modes, each designed to meet specific burner control requirements. These modes ensure flexibility and adaptability across various industrial applications.

On/Off Mode

In On/Off mode, the RM7800 provides basic burner control by switching the burner on or off based on system demands. This mode is suitable for applications where precise modulation is not required, such as in smaller combustion systems or systems with fixed heat demand. The module ensures reliable operation by monitoring the burner’s status and performing safety shutdowns if anomalies are detected.

Modulating Mode

Modulating mode allows for precise control of fuel flow and combustion air, enabling variable burner output. This mode is ideal for applications requiring energy efficiency and consistent process control. The RM7800 uses advanced algorithms to adjust burner output smoothly, ensuring optimal performance and reduced energy consumption. Modulating control is particularly beneficial in large industrial processes where maintaining precise temperatures or pressures is critical.

Combination Fuel Mode

The RM7800 can operate with gas, oil, or combination fuel systems, making it versatile for diverse applications. In combination fuel mode, the module seamlessly switches between fuel types based on availability or system requirements. This feature enhances operational flexibility and ensures uninterrupted production, especially in environments where fuel availability may vary.

Additional Operational Modes

Beyond the primary modes, the RM7800 includes features like valve proving, which verifies the correct operation of gas valves before ignition. This enhances safety by preventing unsafe ignition conditions. Additionally, the module supports flame detection and monitoring, ensuring continuous and reliable burner operation. These features are integral to the module’s design and contribute to its robust operational capabilities.
